JCU-4

    Premium joystick control unit for FLIR Marine cameras - compatible with the M232, M300, M400/M400XR and M500 series.

    £1,595.00

    Model: JCU-4

    SKU: E70695

    Sales Request
    JCU-4: Ultimate Control for FLIR Marine Cameras

    JCU-4: Ultimate Control for FLIR Marine Cameras

    The JCU-4 provides confident control of FLIR marine thermal and visible cameras. Pan, tilt, zoom, and control all the camera functions with JCU-4’s ergonomic keypad and responsive joystick control. Our premier FLIR joystick controller, the JCU-4 pairs seamlessly with FLIR marine thermal cameras and provides the operator a dedicated tactile camera control solution.

    Simple to use, easy to integrate

    Simple to use, easy to integrate

    Designed by mariners, for mariners the JCU-4 is perfect for those who actively navigate using thermal technology and require dependable and intuitive control of their FLIR camera.

    • Rugged, low profile 3-axis joystick for precision camera control in all conditions
    • The 2.9” color LCD and keypad simplify camera operation and offer easy access to the joystick setup menus
    • Dimmable color LCD and back lit keypad preserves the operator’s vision during nighttime operations
    • 3 custom keys for quick access to user-defined camera functions.
    • Pair the JCU-4 with a FLIR marine camera and marine monitor to create a complete camera viewing and control solution
    • Add the JCU-4 to an integrated chartplotter and camera system for a dedicated tactile camera control alternative.

    JCU-4 - Specifications & Resources

    Physical
    Width

    93.66 mm (3.69 in)
    Height

    146.66 mm (5.77 in)
    Depth

    63.36 mm (2.49 in)
    Depth (including joystick)

    113.30 mm (4.46 in)
    Power
    PoE class

    Class 2
    Nominal supply voltage
    • PoE: 48 V dc
    • Alternate power: 12 V / 24 V dc
    Operating voltage range
    • PoE: 44 V to 57 V dc
    • Alternate power: 8 V to 32 V dc
    Power consumption

    5 W Max with full keypad illumination
    IEEE Standard

    IEEE 802.3af
    Network
    Network connection ports
    • 1x 10/100/1000 Mbits/s RayNet (Ethernet)
    • 1x 10/100/1000 Mbits/s PoE RayNet (Ethernet)
    Display
    LCD Size

    2.9”
    LCD Type

    IPS TFT LCD
    Active area

    26.51 mm x 67.68 mm
    Brightness / Luminance

    600 nits / 600 cd/m2
    Viewing angles

    80 + / 80 +
    Resolution

    376 (H) x 960 (W) pixels (RBG)
    Contrast ratio

    1:1500
    Environmental
    Operating temperature

    -25 ºC to +55 ºC (-13 ºF to 131 ºF)
    Storage temperature

    -30 ºC to +70 ºC (-22 ºF to 158 ºF)
    Relative humidity

    Maximum 93% @ + 40 °C (104 °F)
    Waterproof rating

    IPx6
    Certificates
    JCU-4 - Declaration of Conformity - UK


    JCU-4 - Declaration of Conformity - EU


    JCU-4 - Declaration of Conformity - ANZ
